5.7 inch TFT screen

The smallest NS HMI is available in two brightness variations, both with a vivid color TFT touchscreen. It is equipped with a USB connection for project download/upload and the possibility to communicate over Ethernet. One great advantage with the NS is that you can make use of Omron unique Smart Active Parts (SAP) that save you time when configuring, commissioning and maintaining your machine. SAP are pre-programmed, pre-tested visualisation objects with embedded communication code, bringing ‘drag and drop’ simplicity to HMI design.

Perfect clarity and fast switching screens

Extremely long backlight life (up to 75,000 hours)

Support all European languages, Asian and Cyrillic

Easy data logging on compact flash

Large Memory size (60MB)

Specifications & ordering info

Ordering information

Type				Order Code
NS5-TQ	TFT, 5.7”, 320×240 pixels	no Ethernet	Black	NS5-TQ10B-V2
		no Ethernet	Ivory	NS5-TQ10-V2
		with Ethernet	Black	NS5-TQ11B-V2
		with Ethernet	Ivory	NS5-TQ11-V2
NS5-SQ	TFT, 5.7”, 320×240 pixels	no Ethernet	Black	NS5-SQ10B-V2
		no Ethernet	Ivory	NS5-SQ10-V2
		with Ethernet	Black	NS5-SQ11B-V2
		with Ethernet	Ivory	NS5-SQ11-V2

Note: For the accessories, please refer to

Specifications

Item	NS5-TQ	NS5-SQ
Display type	5.7 inch High luminance color TFT	5.7 inch color TFT
Display resolution	340×240 (QVGA)
Number of colors	256 (32.768 for image data)
Backlight	LED
Backlight lifetime	Min. 75000 hours
View angle	Left/right ±80°, Top 80°, Bottom 60°
Touch panel	Matrix resistive touch
Number of functional keys	–
Dimensions in mm (H×W×D)	142×195×54
Weight	1.0 kg max.
Screen data capacity	60 MB
Internal memory	Bit memory: 32,767 bits, Word memory: 32,767 words, Retentative memory: 8,192 bits and 8,192 words.
Memory card interface	1 slot ATA Compact Flash card
Printer connection	PictBridge support
Serial (COM1)	1×RS-232
Serial (COM2)	1×RS-232
USB Slave	For programming & printing
Ethernet	IEEE 802.3u 10Base-T/100Base-TX
Expansion module	–
Line voltage	24 VDC ±15%
Power consumption	15 W max.
Battery	CJ1W-BAT01
Battery lifetime	5 years (at 25°C)
Enclosure rating (front side)	IP65F (equivalent to NEMA4)
Obtained standards	UL 1604 Class 1 Diff. 2, cUL, CE, Lloyds, DNV
Operating environment	No corrosive gases
Noise immunity	Conforms to IEC61000-4-4, 2 KV (power lines)
Ambient operating temperature	0 to 50°C 1
Ambient operating humidity	35% to 85% (0 to 40°C) with no condensation, 35% to 60% (40 to 50°C) with no condensation

Accessories

Ordering information

Type	Description		Order code
Cable	Serial programming cable		XW2Z-S002
Cable	USB programming cable, 2 m		CP1W-CN221
PT-to-PLC Connecting Cable	PT connection: 9 pins PLC connection: 9 pins	Length: 2 m	XW2Z-200T
PT-to-PLC Connecting Cable	PT connection: 9 pins PLC connection: 9 pins	Length: 5 m	XW2Z-500T
Accessories	Video input	Inputs: 4 channels NTSC / PAL	NS-CA001
	Video input	Inputs: 2 channels NTSC / PAL, 1 channel RGB	NS-CA002
	Cable to connect NS-CA00_ to Video console unit		F150-VKP (2 m)
	Cable to connect NS-CA00_ to Video console unit		F150-VKP (5 m)
	Controller link interface unit		NS-CLK21
	RS-422A/485 adapter (50 m)		CJ1W-CIF11
	RS-422A adapter (500 m)		NS-AL002
	Anti-reflection sheets (5 sheets)	NS15	NS15-KBA04
		NS12/10	NS12-KBA04
		NS8	NS7-KBA04
		NS5	NT30-KBA04
	Anti-reflection protective covers (5 pack)	NS12/10	NS12-KBA05
		NS8	NS7-KBA05
		NS5	NT31C-KBA05
	Transparent protective covers (5 pack)	NS15 (1 cover)	NS15-KBA05N
		NS12/10	NS12-KBA05N
		NS8	NS7-KBA05N
		NS5	NT31C-KBA05N
	Chemical-resistant cover (1 cover)	NS5	NT30-KBA01
	Attachment adapter	(NT625C/631/631C series to NS12 series)	NS12-ATT01
		(NT625C/631/631C series to NS12 series) Black	NS12-ATT01B
		(NT620S/620C/600S series to NS8 series)	NS8-ATT01
		(NT600M/600G/610G/612G series to NS8 series)	NS8-ATT02
	Memory card	128 MB	HMC-EF183
		256 MB	HMC-EF283
		512 MB	HMC-EF583
	Memory card adapter for PC		HMC-AP001
	Battery		CJ1W-BAT01

Features

Smart Active Parts

One great advantage with the NS is that you can make use of Omron unique Smart Active Parts (SAP) that save you time when configuring, commissioning and maintaining your machine. SAP are pre-programmed, pre-tested visualization objects with embedded communication code, bringing ‘drag and drop’ simplicity to Human Machine Interface design.
