Degree of protection | IP67 (IEC 60529) and IP67G (JIS C 0920 Annex 1) |
Durability | Mechanical | 4,000,000 operations min. |
Electrical | 500,000 operations min. (Standard load: 1 A at 30 VDC, resistive load/Micro load: 0.1 A at 30 VDC, resistive load) 4,000,000 operations min. (10 mA at 24 VDC, resistive load) |
Operating speed | 0.1 mm/sec to 0.5 m/sec |
Operating frequency | Mechanical: 120 operations/min Electrical: 30 operations/min |
Dielectric strength | Between terminals of same polarity | 1,000 VAC, 50/60 Hz for 1 min |
Between each terminal and
non-current-carrying metal part | 1,500 VAC, 50/60 Hz for 1 min/U
imp
at 2.5 kV
(EN 60947-5-1) |
Vibration resistance | Malfunction | 10 to 55 Hz, 1.5-mm double amplitude |
Shock resistance | Destruction | 1,000 m/s
2
max. (IEC 68-2-27) |
Malfunction | 300 m/s
2
max. (IEC 68-2-27) |
Ambient operating temperature | 5
°
C to 70
°
C (with no icing or condensation) |
Ambient operating humidity | 35% to 95%RH (with no condensation) |
