Linear actuators are electromechanical devices providing a linear movement, in contrast with the rotatory motion of the applied electric motor.
The linear actuator transforms a rotation into a linear movement of pushing, pulling, lifting or positioning loads even up to 20 tons.
The use of the electric system leads to a series of benefits if compared to hydraulic and pneumatic ones, as being suitable for many applications in different industrial fields.
Max. load 1.200 N
Max. speed 90 mm/s
Motor 12-24 Vdc
Max. load 2.500 N
Max. speed 16,5 mm/s
Motor 12-24 Vdc
Max. load 2.500 N
Max. speed 110 mm/s
Motor 1ph-3ph Vac-Vdc
Max. load 4.200 N
Max. speed 30 mm/s
Motor 12-24 Vdc
Max. load 6.000 N
Max. speed 35 mm/s
Motor 12-24 Vdc-Vac
Max. load 10.000 N
Max. speed 100 mm/s
Motor 12-24 Vdc-Vac
Max. load 15.000 N
Max. speed 50 mm/s
Motor 1ph-3ph Vdc-Vac
Max. load 18.000 N
Max. speed 93 mm/s
Motor 1ph-3ph Vac
Max. load 18.000 N
Max. speed 113 mm/s
Motor 1ph-3ph Vac
Max. load 15.000 N
Max. speed 170 mm/s
Motor chosen by client
. (servo/
. brushless/
. stepper)
Max. load 25.000 N
Max. speed 55 mm/s
Motor 1ph-3ph Vac
EC1
Max. load 5.000 N
Max speed 230 mm/s
Motor 1ph-3ph Vac
EC2
Max. load 10.000 N
Max speed 230 mm/s
Motor 1ph-3ph Vac
EC3
Max. load 15.000 N
Max speed 230 mm/s
Motor 1ph-3ph Vac
EC4
Max. load 30.000 N
Max speed 60 mm/s
Motor 1ph-3ph Vac
EC5
Max. load 50.000 N
Max. speed 15 mm/s
Motor 1ph-3ph Vac
Max. load 15.000 N
Max. speed 20 mm/s
MotorDC
Max. load 200.000 N
Max. speed 50 mm/s
Motor AC
Max. load 2.000 N
Max. speed 100 mm/s
Motor 12-24 Vdc
Max. load 5.000 N
Max. speed 30 mm/s
Motor 12-24 Vdc
