| Design | Integrated earth fault monitor |
|---|
| Frequency AC [Hz] | 47…63 |
|---|---|
| Nominal voltage AC [V] | 110 / 230 |
| Input voltage range AC [V] | 85…132 / 184…264 |
| Protection class | I |
| Max. power-on delay time [ms] | 100 |
| Output voltage AS-i [V] | 30.5 |
| Output power (permanent) [W] | 122 |
| Number of output circuits | 1 |
| Output current AS-i [A] | 4 |
| Max. residual ripple [mV] | 50 |
| External input protection | B 6 A |
| Derating [W/K] | 3 (60…70 °C) |
| Integrated data decoupling | yes |
| Short-circuit protection | yes |
|---|---|
| Type of short-circuit protection | electronically protected |
| Overload protection | yes |
| Parallel connection of outputs possible | no |
| Series connection of outputs possible | no |
| Ambient temperature [°C] | -10…70 | |
|---|---|---|
| Note on ambient temperature |
|
|
| Protection | IP 20 | |
| Pollution degree | 2; (IEC 62103: conductive soiling not permitted) |
| EMC |
|
||||||
|---|---|---|---|---|---|---|---|
| MTTF [years] | 139 |
| AS-i certificate | 42301 |
|---|
| Weight [g] | 750 |
|---|---|
| Dimensions [mm] | 124 x 73 x 107 |
| Materials | housing: steel sheet |
| Display |
|
|---|
| Pack quantity | 1 pcs. |
|---|
| Connection | terminals: …4 mm² |
|---|
