$365,00
| Number of inputs and outputs | Number of analogue inputs: 4 |
|---|
| Application | field installation |
|---|
| Operating voltage [V] | 18…31.6 DC |
|---|---|
| Max. current consumption from AS-i [mA] | 50 |
| Reverse polarity protection | yes |
| Max. current load total [A] | 2 |
| Additional voltage supply [V] | 16…30 DC; (AUX) |
| Max. current consumption from additional supply [mA] | 2000 |
| Number of inputs and outputs | Number of analogue inputs: 4 |
|---|
| Sensor supply of the inputs | AUX |
|---|---|
| Number of analogue inputs | 4; (connection of 2- and 3-wire sensors) |
| Analogue input (current) [mA] | 4…20 |
| Max. voltage drop across load for nominal voltage [V] | 10 |
| Analogue inputs protected against short circuits | yes |
| Resolution of analogue input | 12 bit |
| Accuracy | 0.5; (% of the final value of the measuring range; tolerance under the influence of electromagnetic interference: < ± 1 % of the final value of the measuring range) |
|---|
| Ambient temperature [°C] | -25…70 |
|---|---|
| Storage temperature [°C] | -25…70 |
| Max. relative air humidity [%] | 90; (non condensing) |
| Max. height above sea level [m] | 2000 |
| Protection | IP 67 |
| EMC |
|
||||||
|---|---|---|---|---|---|---|---|
| MTTF [years] | 105 | ||||||
| UL approval |
|
| AS-i version | 2.11; 3.0 |
|---|---|
| Extended addressing mode | no |
| AS-i profile | S-7.3.E |
| AS-i I/O configuration [hex] | 7 |
| AS-i ID code [hex] | 3.E |
| AS-i certificate | 123501 |
| Weight [g] | 154.35 |
|---|---|
| Materials | PA; piercing contacts: CuSn6 nickel-plated and tin-plated |
| Display |
|
|---|
| Module connection | Flat cables |
|---|
| Items supplied |
|
|
|---|---|---|
| Accessories (optional) |
|
| Remarks |
|
||
|---|---|---|---|
| Pack quantity | 1 pcs. |
| quick mounting technology for AS-i flat cable: ; three orientations possible | |
| Connector: M12; coding: A |
