| Dimensions W x L x H | (incl. interlinking block)50 mm x 107 mm x 55 mm |
| No. of inputs | 4 |
| Diagnostics | Limit value violation per channelParameterization errorSensor limit per channel |
| Parameterization | Diagnostic delay per channelHysteresis per moduleUnit of measurementMeasured value smoothing per channelLimit value monitoring per channel diagnosticsSensor limit per channel diagnosticsRelative/differential pressure measurement |
| Measured variable | 4x relative pressure/2x differential pressure |
| Displayable unit(s) | kPambarpsi |
| LED indicators | 1 group diagnostics |
| Internal cycle time | 5 ms |
| DC operating voltage range | 18 V … 30 V |
| Intrinsic current consumption at nominal operating voltage | Typ. 50 mA |
| Nominal operating voltage DC | 24 V |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Corrosion resistance class (CRC) | 1 – Low corrosion stress(when installed) |
| Storage temperature | -20 °C … 70 °C |
| Temperature of medium | 0 °C … 50 °C |
| Degree of protection | IP65IP67 |
| Ambient temperature | -5 °C … 50 °C |
| Product weight | 115 g |
| Pressure measuring range end value | 10 bar |
| Pressure measuring range initial value | 0 bar |
| Data format | 15 bit + signBinary representation in mbar, kPa, psi |
| Pneumatic connection | QS-4 |
| Note on materials | RoHS-compliant |
| Housing material | PA-reinforcedPC |
