CP1L-L10DR-D

PLC, 24 VDC supply, 6 x 24 VDC inputs, 4 x relay outputs 2 A, 5K steps program + 10K words data memory



SKU: CP1L-L10DR-D
ID:1585809

Description

Supply voltage type DC
Number of digital inputs 6
Input type PNP/NPN
Number of digital outputs 4
Output type Relay
Program capacity 5 K steps
Data memory capacity 10 K words
Logic execution time 0.55 µs
Communication port(s) USB
Number of Ethernet ports 0
Number of USB ports 1
Number of RS-232 ports 0
Number of RS-485 ports 0
Communication option(s) None
Number of encoder input channels 4
Max. encoder input frequency 100 kHz
Max. number of PTP axes 0
Max. pulse output frequency 0 kHz
Function Block programming ✔️
Battery-free memory backup
Real-time clock ✔️
Analogue option boards
Max. number of analogue I/O channels 1
Max. number of local I/O points 10
Max. number of expansion units 0
Built-in auxiliary 24 VDC output 0 mA
Operating temperature range 0-55 °C
Product Height (unpacked) 90 mm
Product Width (unpacked) 66 mm
Product Depth (unpacked) 85 mm
Product Weight (unpacked) 275 g



Accessories

CP1W-CN221 USB Programming cable, A-type male to B-type male, 1.8 m



CP1W-ME05M CP1 memory cassette (for upload/download of user program)



CXONE-LT01-EV4 CX-One Lite v4.x software, for Windows 2000/XP/Vista, single-user licence only, (requires CDs, CXOne-LTCD-EV4), limited to program the CPx PLC platform
