PLC, 24 VDC supply, 36 x 24 VDC inputs, 24 x NPN outputs 0.3 A, 10K steps program + 32K words data memory
| Supply voltage type | DC |
| Number of digital inputs | 36 |
| Input type | PNP/NPN |
| Number of digital outputs | 24 |
| Output type | NPN |
| Program capacity | 10 K steps |
| Data memory capacity | 32 K words |
| Logic execution time | 0.55 µs |
| Communication port(s) | USB |
| Number of Ethernet ports | 0 |
| Number of USB ports | 1 |
| Number of RS-232 ports | 0 |
| Number of RS-485 ports | 0 |
| Communication option(s) | CompoBus/S Slave, Serial RS-232C, Serial RS-422, Serial RS-485 |
| Number of encoder input channels | 4 |
| Max. encoder input frequency | 100 kHz |
| Max. number of PTP axes | 2 |
| Max. pulse output frequency | 100 kHz |
| Function Block programming | ✔️ |
| Battery-free memory backup | ❌ |
| Real-time clock | ✔️ |
| Analogue option boards | ❌ |
| Max. number of analogue I/O channels | 25 |
| Max. number of local I/O points | 180 |
| Max. number of expansion units | 3 |
| Built-in auxiliary 24 VDC output | 0 mA |
| Operating temperature range | 0-55 °C |
| Product Height (unpacked) | 90 mm |
| Product Width (unpacked) | 195 mm |
| Product Depth (unpacked) | 85 mm |
| Product Weight (unpacked) | 680 g |
 |
CP1W-CIF01 | CP1 RS-232C (15 m max.) serial communication option board |
|
 |
CP1W-CIF11 | CP1 RS422/485 (50 m max.) serial communication option board |
|
|
CP1W-CIF12-V1 | CP1 RS422/485 (isolated 500 m max.) serial communication option board |
|
 |
CP1W-CIF41 | CP1 Ethernet communications option, 1 x RJ45 socket |
|
 |
CP1W-CN221 | USB Programming cable, A-type male to B-type male, 1.8 m |
|
 |
CP1W-CN811 | I/O expansion cable for CP1-series, 80 cm |
|
 |
CP1W-DAM01 | LCD option board to CP1L and CP1H |
|
 |
CP1W-ME05M | CP1 memory cassette (for upload/download of user program) |
|
 |
CXONE-LT01-EV4 | CX-One Lite v4.x software, for Windows 2000/XP/Vista, single-user licence only, (requires CDs, CXOne-LTCD-EV4), limited to program the CPx PLC platform |
|
CP-series CP1L CPU Unit
CP1 CPU Unit
CP1 Series
CP1E/CP1L
CP1L CPU Unit
CP1L CPU Unit (including CP1L-J)
CP1L-EL, CP1L-EM CPU Unit
