| Radio approval for | EU/RED; USA; Canada | |
|---|---|---|
| Note on radio approval |
|
| Operating voltage [V] | 8…32 DC |
|---|---|
| Nominal voltage DC [V] | 12 / 24 |
| Nominal voltage tolerance [%] | 50 |
| Nominal voltage tolerance 2 [%] | 50 |
| Current consumption [mA] | < 250; (normal operation; sleep mode: < 500 µA) |
| Number of inputs and outputs | Number of analogue inputs: 3; Number of digital outputs: 1 |
|---|
| Number of analogue inputs | 3 |
|---|---|
| Analogue input (voltage) [V] | 0…15 |
| Resolution of analogue input | 12 Bit |
| Number of digital outputs | 1 |
|---|---|
| Voltage range DC [V] | 6…36 |
| Permanent current rating of switching output DC [mA] | 500 |
| Resolution | [acceleration measurement]: 16 bit; [inclination measurement]: 16 bit |
|---|
| Resolution | 16 bit |
|---|---|
| Sampling rate [Hz] | 10 |
| Number of measurement axes | 3 |
| Measuring range acceleration [g] | ± 16 |
| Resolution | 16 bit |
|---|---|
| Sampling rate [Hz] | 10 |
| Number of measurement axes | 3 |
| Measuring range vehicle yaw rate [°/s] | ± 250 |
| Communication interface | CAN; Mobile networks |
|---|---|
| Number of CAN interfaces | 1 |
| Number of USB interfaces | 1 |
| Interface | CAN Interface 2.0 A/B ISO 11898 |
|---|
| Note on interfaces |
|
|---|
| Transmission standard | GSM; GPRS; EDGE; UMTS; HSPA; 3G; 4G; LTE Cat-4 | ||
|---|---|---|---|
| Frequency band | GSM / GPRS / EDGE / 2G: 850 / 900 / 1800 / 1900; UMTS / HSPA / 3G: 850 (B5) / 900 (B8) / 1700 (B4) / 1900 (B2) / 2100 (B1); 4G / LTE Cat 4: 700 (B12, B17) / 750 (B13, B28) / 800 (B20) / 850 (B5) / 900 (B8) / 1700 (B4) 1800 (B3) / 1900 (B2) / 2100 (B1) / 2600 (B7) | ||
| Note on interfaces |
|
| Connector type | Mirco-AB |
|---|---|
| Usage type | firmware update |
| Ambient temperature [°C] | -40…85 |
|---|---|
| Protection | IP 67 |
| Standard | EN 61000-6-2; EN 61000-6-3; IEC 62368-1; UN/ECE-R10; EN ISO 13766-1; ISO 7637-2; IEC 60068-2-30; IEC 60068-2-6; IEC 60068-2-27; IEC 60068-2-31 |
|---|
| Weight [g] | 233.7 |
|---|---|
| Materials | housing: PA black |
| Display |
|
|---|
| Processor | ARM Cortex M4 based STM32 (168 MHz) |
|---|---|
| Working memory | Program Flash: 1 MBFRAM: 32 KBSRAM: 1280 KB |
| Mass storage | 128 MB |
| Real-time clock | yes; UTC, battery buffered |
|---|
| Pack quantity | 1 pcs. |
|---|
