| Installation | rail TH35; according to EN 60715 |
|---|
| Operating voltage [V] | to SELV/PELV |
|---|---|
| Nominal voltage DC [V] | 24 |
| Input voltage DC [V] | 19.2…30 |
| Protection class | III |
| Reverse polarity protection | yes |
| Mains buffering time (nominal voltage 24 V DC) [ms] | 10 |
| Closed-circuit current [mA] | 12 |
| Number of channels | 2 |
| Nominal current [A] | 1…10 |
| Nominal current (Fail Safe Element) [A] | 10 |
| Load capacitance, total [mF] | 20 |
|---|
| Ambient temperature [°C] | -25…60 |
|---|---|
| Storage temperature [°C] | -40…70 |
| Protection | IP 20; (on the front) |
| Pollution degree | 2 |
| EMC |
|
|---|
| Weight [g] | 73.5 |
|---|---|
| Dimensions [mm] | 80 x 12.5 x 98 |
| Display |
|
||
|---|---|---|---|
| Operating elements |
|
| Connection | push-in terminals: |
|---|
