MODELS |
Measuring Units |
Measuring Units |
Accuracy1 |
Resolution |
|
MP 110 |
Pa, mmH2 O inWg, daPa |
From -1000 to +1000 Pa |
±0.5% of reading ±2 Pa |
1 Pa |
|
MP 111 |
Kpa, mmH2 O, inWg, mbar, mmHg, daPa |
From -1000 to +1000 mmH2 O |
±0.5% of reading ±2 mmH2 O |
De 0 à ±200 mmH2 O : 0,1 mmH2 O Au delà : 1 mmH2 O |
|
MP 115 |
kPa, inWg, mbar, mmHg, PSI |
From -500 to +500 mbar |
±0.5% of reading ±0.5 mbar |
0.1 mbar |
|
MP 112 |
kPa, inWg, mbar, mmHg, PSI, bar |
From -2000 to +2000 mbar |
±0.5% of reading ±2 mbar |
1 mbar |
GENERAL DETAILS
Easy to use
Adjustable backlight
Hold-min-max function
Selection of Units
Manuel Autozero
FUNCTIONS
Pressure Measurement
Selections of Units
Manual Autozero
Hold Function
Display of minimum and maximum values
Configurable auto shut-off
Backlight
TECHNICAL SPECIFICATIONS
Measuring elements : Piezoresistive sensor
Tolerated overpressure : MP 110 : 250 mbar / MP 111 : 700 mbar
MP 115 : 1.4 bar / MP 112 : 3 bar
Connector : MP 110 / 111 : Ø 6.2 mm barbed connectors made of nickelled brass
MP 115 / 112 : Ø 4.6 mm threaded connectors of nickelled brass
Display : 4 lines, LCD technology. Sizes 50 x 36 mm.
2 lines of 5 digits with 7 segments (value)
2 lines of 5 digits with 16 segments (unit)
Housing : ABS, protection IP54
Keypad : 5 keys
Conformity : Directives EMC 2004/108/CE and EN 61010-1
Power supply : 4 batteries AAA LR03 1.5 V
Autonomy : 180 hours
Ambience : Neutral gas
Operating temperature : From 0 to +50 °C
Storage temperature : From -20 to +80 °C
Auto shut-off : Adjustable from 0 to 120 min
Weight : 220 g
