| Application | signalling machine conditions |
|---|
| Operating voltage [V] | 18…30 DC; (to SELV/PELV) |
|---|---|
| Nominal voltage DC [V] | 24 |
| Current consumption [mA] | < 200 |
| Input current High [mA] | 6 |
|---|
| Communication interface | IO-Link | ||||
|---|---|---|---|---|---|
| Transmission type | COM2 (38,4 kBaud) | ||||
| IO-Link revision | 1.1 | ||||
| SDCI standard | IEC 61131-9 | ||||
| SIO mode | yes | ||||
| Required master port type | A | ||||
| Min. process cycle time [ms] | 3.2 | ||||
| Supported DeviceIDs |
|
| Ambient temperature [°C] | -25…50 |
|---|---|
| Storage temperature [°C] | -40…75 |
| Max. relative air humidity [%] | 90 |
| Air pressure [kPa] | < 106 |
| Max. height above sea level [m] | 2000 |
| Protection | IP 54 |
| UL approval |
|
|---|
| Weight [g] | 422.8 |
|---|---|
| Dimensions [mm] | Ø 70 / L = 220 |
| Materials | housing: ABS; lens: PC |
| Display |
|
||
|---|---|---|---|
| Acoustic signal | buzzer | ||
| Max. sound pressure [dB] | 85 |
| Accessories (optional) |
|
|---|
| Remarks |
|
|
|---|---|---|
| Pack quantity | 1 pcs. |
| Connector: M12; coding: A |
