FH high-speed / high performance controller 4-core, NPN/PNP, 2 cameras
| Performance | High |
| Processor family | Intel® Core™ i7 |
| Operating system | WES 7 (64 bits) |
| Memory | 8 GB RAM (non ECC) |
| AI Scratch detection filter | ✔ |
| AI FineMatching | ✔ |
| Number of cameras | 2 |
| Integrated monitor | ❌ |
| Communication port(s) | EtherCAT Slave, EtherNet/IP, Ethernet TCP/IP, PROFINET Slave, Serial RS-232C, USB |
| Output type | PNP/NPN |
| Application | 2D Robot guidance, 3D Bin picking, AI fine matching, AI scratch detection, Bead inspection, Code reading, Code verification, Color inspection, Counting, Defect inspection, Measurement inspection, OCR / OCV, Presence / Absence |
 |
FH-MT12 | Vision system FH touch panel monitor 12-inch |
|
 |
FH-SC | FH camera, standard resolution, colour |
|
 |
FH-SC02 | FH camera, high resolution 2M pixel, color |
|
|
FH-SC04 | FH camera, high resolution 4M pixel, color |
|
 |
FH-SC05R | FH camera, high resolution 5 m pixel, color, rolling shutter |
|
 |
FH-SC21R | FH Camera, high speed, 20.4 MPixel, c-Mount, rolling shutter, color |
|
 |
FH-SCX | FH Camera, high speed, 0.4 MPixel, c-Mount, global shutter, color |
|
|
FH-SCX01 | FH Camera, high speed, 1.6 MPixel, C-Mount, global shutter, colour |
|
 |
FH-SCX03 | FH Camera, high speed, 3.2 MPixel, C-Mount, global shutter, colour |
|
|
FH-SCX05 | FH Camera, high speed, 5 MPixel, c-Mount, global shutter, color |
|
|
FH-SCX12 | FH Camera, high speed, 12 MPixel, C-Mount, global shutter, color |
|
 |
FH-SM | FH camera, standard resolution, monochrome |
|
|
FH-SM02 | FH camera, high resolution 2M pixel, monochrome |
|
|
FH-SM04 | FH camera, high resolution 4M pixel, monochrome |
|
 |
FH-SM05R | FH camera, high resolution 5 m pixel, monochrome, rolling shutter |
|
|
FH-SM21R | FH Camera, high speed, 20.4 MPixel, c-Mount, rolling shutter, monochrome |
|
 |
FH-SMX | FH Camera, high speed, 0.4 MPixel, c-Mount, global shutter, monochrome |
|
|
FH-SMX01 | FH Camera, high speed, 1.6 MPixel, C-Mount, global shutter, monochrome |
|
|
FH-SMX03 | FH Camera, high speed, 3.2 MPixel, C-Mount, global shutter, monochrome |
|
|
FH-SMX05 | FH Camera, high speed, 5 MPixel, c-Mount, global shutter, monochrome |
|
|
FH-SMX05-PL | FH polarised camera, high speed, 5 MPixel, C-Mount, global shutter, monochrome |
|
|
FH-SMX12 | FH Camera, high speed, 12 MPixel, C-Mount, global shutter, monochrome |
|
|
FH-SMX12-PL | FH polarised camera, high speed, 12 MPixel, C-Mount, global shutter, monochrome |
|
 |
FH-UMAI1 | AI filter installer for FH controller. USB license key dongle |
|
 |
FH-VMDA 2M | Vision system accessory FH conversion cable monitor DVI-RGB 2 m |
|
|
FH-VMDA 5M | Vision system accessory FH conversion cable monitor DVI-RGB 5 m |
|
 |
FH-VUAB 2M | Vision system accessory FH USB cable touch panel 2 m |
|
|
FH-VUAB 5M | Vision system accessory FH USB cable touch panel 5 m |
|
 |
FZ-VS3 10M | Accessory vision, FH and FZ, standard camera cable, 10m |
|
|
FZ-VS3 2M | Accessory vision, FH and FZ, standard camera cable, 2m |
|
|
FZ-VS3 3M | Accessory vision, FH and FZ, standard camera cable, 3m |
|
|
FZ-VS3 5M | Accessory vision, FH and FZ, standard camera cable, 5m |
|
 |
FZ-VS4 15M | Accessory vision, FH and FZ, camera cable, long distance, 15m |
|
 |
FZ-VSB3 10M | Accessory vision, FH and FZ, camera cable, bend resistant, 10 m |
|
|
FZ-VSB3 5M | Accessory vision, FH and FZ, camera cable, bend resistant, 5 m |
|
| FZ-VSJ | FZ Camera cable extension hub (max 3 cables 45m) |
|
|
 |
GX-JC03 | 3-port EtherCAT Junction module, 24 VDC power supply |
|
 |
GX-JC06 | 6-port EtherCAT Junction module, 24 VDC power supply |
|
 |
W4S1-05D | 5-port enhanced Ethernet switch |
|
| XW2Z-200EE | Parallel I/O cable for terminal block XW2R-_34G-T, 2 m |
|
|
 |
XW2Z-S013-2 | Parallel I/O cable, 2m, for FH series only |
|
