Digital counter, screw terminals, 48×48 mm, IP66, 6 count digits, multifunction: 1&2-stage, total, batch, dual, twin counter, tachometer, SPDT relay & SPST transistor output, 12-48 VDC / 24 VAC supply, 12 VDC aux. supply
| Type | Pre-set counter |
| Size | 1/16 DIN (48 x 48 mm) |
| Counting functions | 1-stage counter, 1-stage counter with batch counter, 1-stage counter with total counter, 2-stage counter, Dual counter (addition/subtraction), Tachometer, Twin counter |
| Counting range | -99999 – 999999 |
| LCD backlight | With backlight |
| Number of digits | 6 |
| Body color | Black |
| Installation type | On-panel |
| Terminal | Screw |
| Output type | Relay, Transistor |
| Relay output | 1 |
| Transistor output | 1 |
| Inputs | DC voltage, No-voltage |
| Supply voltage AC | 20.4-26.4 V |
| Supply voltage DC | 12-48 V |
| Speed | 10000 Hz |
| Product Width (unpacked) | 48 mm |
| Product Height (unpacked) | 48 mm |
| Product Depth (unpacked) | 78 mm |
 |
Y92A-48 | Protective cover for DIN48x48mm device, hard plastic (shallow) |
|
 |
Y92A-48F1 | Protective cover for DIN 48 x 48 mm timer and counter, soft plastic |
|
 |
Y92F-45 | Panel adaptor, 48 x 48 device into 67 x 67 hole |
|
