$256,30
| Electrical design | NPN |
|---|---|
| Output function | normally open |
| Sensing range [mm] | 20…70 |
| Housing | cylindrical |
| Dimensions [mm] | Ø 100 / L = 40 |
| Operating voltage [V] | 10…36 DC |
|---|---|
| Current consumption [mA] | 15; (24 V) |
| Protection class | II |
| Reverse polarity protection | yes |
| Electrical design | NPN |
|---|---|
| Output function | normally open |
| Max. voltage drop switching output DC [V] | 2.5 |
| Permanent current rating of switching output DC [mA] | 250 |
| Switching frequency DC [Hz] | 5 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
| Sensing range [mm] | 20…70 |
|---|---|
| Sensing range adjustable | yes |
| Factory setting sensing range [mm] | 70 |
| Real sensing range Sr [mm] | 70 ± 10 % |
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminium: 0.4 / copper: 0.3 |
|---|---|
| Hysteresis [% of Sr] | < 15 |
| Switch point drift [% of Sr] | -15…15 |
| Ambient temperature [°C] | -20…70 |
|---|---|
| Protection | IP 65 |
| EMC |
|
|---|
| Weight [g] | 515.5 |
|---|---|
| Housing | cylindrical |
| Mounting | non-flush mountable |
| Dimensions [mm] | Ø 100 / L = 40 |
| Materials | PBT |
| Display |
|
|---|
| Pack quantity | 1 pcs. |
|---|
| Connection | Cable: 2 m, PVC; 3 x 0.5 mm² |
|---|
