K61 – PNEUMATIC PISTON SEAL

SKU: K61 – PNEUMATIC PISTON SEAL
ID:88514

Description

K61 is a double-acting pneumatic piston seal, which is a a compact sealing element in one piece consists of POM guide rings, NBR sealing ring (dynamic and static) and aluminum body.

Advantages

• No need for machined piston head
• Superior guiding feature
• High friction resistance
• Easy installation
• Long service life

Area of Application

• Pneumatic Cylinders

Material
Code
Pressure
(max) bar
Temperature
(max) °C
Sliding Speed
(max)- m/s
NBR, POM
ALIMINUM,
NBR
NB8001, PM9901
AL9901, NB7001
12
-30/+100
1.0
