K76 – PISTON-ROD GUIDE RING

SKU: K76 – PISTON-ROD GUIDE RING
ID:88751

Description

K76 piston-rod guide rings are composite guiding elements, produced from polyester fabric and phenolic resin which provides high load carrying capacity designed to be used in rod and piston applications in hydraulic systems.

Advantages

• Low coefficient of friction
• High Load bearing capacity
• The high form stability at operating temperature range
• Low swelling
• Wide range of dimensions

Area of Application

• Mobile machinery
• Mining industry
• Excavators
• Presses
• Heavy duty cylinders

Material
Code
Pressure
(max) bar
Temperature
(max) °C
Sliding Speed
(max)- m/s
POLYESTER
FIBER,
PHENOLIC
RESIN
PH6502

-40/+120
1.0
