K79 piston-rod guide rings are composite guiding elements, produced from syntethic fabric and polyester resin which provides high load carrying capacity designed to be used in rod and piston applications in hydraulic systems. Different from regular composite guide rings, K79 has a grapphite additives which decreases friction and provides self-lubrication so widely preffered in dry applications or cylinders with insufficient lubrication.
Advantages
• Low coefficient of friction • Able to work dry behind the sealing element • The high form stability at operating temperature range • Easy installation • Can be used in heavy and medium duty applications
Area of Application
• Mobile machinery • Pneumatic cylinders • Excavators • Presses
Material
Code
Pressure (max) bar
Temperature (max) °C
Sliding Speed (max)- m/s
SENTETİK FİBER, POLYESTER RESİN, GRAFİT
PH6503
-40/+120
5.0
