$265,60
| Electrical design | PNP |
|---|---|
| Output function | normally open / normally closed; (selectable) |
| Sensing range [mm] | 60 |
| Housing | rectangular |
| Dimensions [mm] | 105 x 80 x 40 |
| Operating voltage [V] | 10…36 DC |
|---|---|
| Current consumption [mA] | 5; (24 V) |
| Protection class | II |
| Reverse polarity protection | yes |
| Electrical design | PNP |
|---|---|
| Output function | normally open / normally closed; (selectable) |
| Max. voltage drop switching output DC [V] | 2.5 |
| Permanent current rating of switching output DC [mA] | 250 |
| Switching frequency DC [Hz] | 10 |
| Short-circuit proof | yes |
| Overload protection | yes |
| Sensing range [mm] | 60 |
|---|---|
| Real sensing range Sr [mm] | 60 ± 10 % |
| Operating distance [mm] | 0…48.6 |
| Correction factor | glass: 0.4 / water: 1 / ceramics: 0.2 / PVC: 0.2 |
|---|---|
| Hysteresis [% of Sr] | 1…15 |
| Switch point drift [% of Sr] | -15…15 |
| Ambient temperature [°C] | -25…80 |
|---|---|
| Protection | IP 65 |
| EMC |
|
||
|---|---|---|---|
| MTTF [years] | 537 |
| Weight [g] | 309.5 |
|---|---|
| Housing | rectangular |
| Mounting | non-flush mountable |
| Dimensions [mm] | 105 x 80 x 40 |
| Materials | PPE modified |
| Display |
|
|---|
| Items supplied |
|
|---|
| Pack quantity | 1 pcs. |
|---|
| Connector: 1 x M12; coding: A |
