| Design | Rectangular |
| Based on norm | EN 60947-5-2VDI/VDE 3845 |
| Certification | RCM compliance markc UL us – Recognized (OL) |
| CE marking (see declaration of conformity) | As per EU EMC directive |
| KC characters | KC EMC |
| Certificate issuing authority | UL E232949 |
| Note on materials | Contains paint-wetting impairment substancesRoHS-compliant |
| Measuring principle | Inductive |
| Ambient temperature | -25 °C … 70 °C |
| Switching output | PNP |
| Switching element function | N/O contact |
| Max. switching frequency | 1000 Hz |
| Max. output current DC | 200 mA |
| Voltage drop | 2.5 V |
| Residual current | 0 mA … 0.5 mA |
| Short-circuit protection | Pulsed |
| DC operating voltage range | 10 V … 30 V |
| Idle current | 22.5 mA |
| Reverse polarity protection | for all electrical connections |
| Electrical connection, input | PlugM12x14-pin |
| Mounting position | Any |
| Product weight | 48 g |
| Housing material | PBT |
| Material of screws | High-alloy stainless steel |
| Ready status indication | LED green |
| Switching status indication | LED yellow |
| Status indicator | LED yellow = pneumatic valve switching statusLED green = power supply indicator |
| Storage temperature | -40 °C … 85 °C |
| Degree of protection | IP67 |
| Shock resistance | Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27 |
| Vibration resistance | Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6 |
| Contamination level | 3 |
