NX102-9000

Sysmac NX1 Modular CPU, 5MB program and 33.5MB data memory , built-in EtherCAT (0 servo axes, 4 PTP axes, total 64 EtherCAT nodes), 2 Ethernet ports (OPC-UA and EtherNet/IP)



SKU: NX102-9000
ID:1587636

Description

Controller functionality OPC-UA, Position control, Sequence control
Max. number of synchronous axes 0
Max. number of PTP axes 4
Max. number of axes (incl. virtual) 4
Primary task cycle time 1 ms
Program memory 5 MB
Variables memory 33.5 MB
Communication port(s) EtherCAT Master, EtherNet/IP, Ethernet TCP/IP
Communication option(s) Serial RS-232C, Serial RS-422, Serial RS-485
Max. number of remote I/O nodes 64
I/O system NX I/O Bus
Max. number of expansion units 32
Product Height (unpacked) 100 mm
Product Width (unpacked) 66 mm
Product Depth (unpacked) 100 mm



Accessories

CJ1W-BAT01 Battery for CJ1M PLCs



GX-JC03 3-port EtherCAT Junction module, 24 VDC power supply



GX-JC06 6-port EtherCAT Junction module, 24 VDC power supply



GX-JC06-H 6-port EtherCAT Junction module, 24 VDC power supply, with node switches



HMC-SD492 4 GB SD memory card



W4S1-05D 5-port enhanced Ethernet switch





Spare parts

NX-END02 Spare part – End plate for NX1P controller





CSM_NX1_P130-E1_DITA_4_11

Datasheet
EN PDF
