$423,10
| Type of light | infrared light |
|---|
| Special feature | Gold-plated contacts |
|---|---|
| Illuminated field [mm] | 50 x 50 |
| Design | backlight |
| Type of operation | Permanent light or pulse operation |
| Operating voltage tolerance [%] | -10…10 |
|---|---|
| Operating voltage [V] | 24 DC |
| Current consumption [mA] | < 325 |
| Protection class | III |
| Reverse polarity protection | yes |
| Type of light | infrared light |
| Wave length [nm] | 875 |
| Trigger | 5…24 V |
|---|
| Ambient temperature [°C] | -10…50 |
|---|---|
| Protection | IP 54 |
| Overheat protection | yes; (> 50 °C) |
| Photobiological safety | exempt group; (EN 62471) |
|---|---|
| MTTF [years] | 309 |
| Weight [g] | 264.4 | |
|---|---|---|
| Dimensions [mm] | 105 x 81 x 9.8 | |
| Materials | aluminium | |
| Lens material |
|
| Display |
|
|---|
| Pack quantity | 1 pcs. |
|---|
| Connection | Cable: 0.30 m, PUR |
|---|---|
| Connection | Connector: 1 x M12; coding: A; Contacts: gold-plated |
Datasheet
EN PDF
