$70,30
| Type of light | red light |
|---|---|
| Housing | rectangular |
| Function principle | Through-beam sensor |
|---|---|
| Application | suited for use in the machine tool industry |
| Operating voltage [V] | 10…30 DC |
|---|---|
| Current consumption [mA] | 11; ((24 V)) |
| Protection class | III |
| Type of light | red light |
| Wave length [nm] | 633 |
| Transmitter / receiver | transmitter |
|---|---|
| Range [m] | < 10 |
| Max. light spot diameter [mm] | 300 |
| Light spot dimensions refer to | at maximum range |
| Ambient temperature [°C] | -25…60 |
|---|---|
| Protection | IP 65; IP 67; IP 68 |
| EMC |
|
||
|---|---|---|---|
| MTTF [years] | 2942 | ||
| UL approval |
|
| Weight [g] | 33.7 | |
|---|---|---|
| Housing | rectangular | |
| Dimensions [mm] | 34.8 x 13 x 21 | |
| Materials | housing: stainless steel (1.4404 / 316L); plastics: PPSU; Sealing: FKM | |
| Lens material |
|
|
| Lens alignment | side lens | |
| Tightening torque [Nm] | 1; (screws) |
| Display |
|
|---|
| Remarks |
|
|
|---|---|---|
| Pack quantity | 1 pcs. |
| Connection | Connector: 1 x M8; coding: A |
|---|
Datasheet
EN PDF
