| Dimensions W x L x H | (incl. interlinking block and connection system)50 mm x 107 mm x 55 mm |
| No. of outputs | 2 |
| Diagnostics | Wire break per channelShort circuit/overload per channelCross circuitUndervoltage of pneumatic valves |
| Parameterization | Diagnostic behaviorWire break monitoring per channel |
| Safety function | Safely switching off supply voltage for the pneumatic valves |
| Safety integrity level (SIL) | Safe switch-off/SIL 3 |
| Performance Level (PL) | Safe switch-off/category 3, performance level e |
| LED indicators | 1 fail-safe mode protocol active1 group diagnostics3 channel diagnostics3 channel status |
| Fuse protection (short circuit) | Internal electronic fuse per channel |
| Intrinsic current consumption at nominal operating voltage | Typ. 25 mA (electronics operating voltage supply)Typ. 65 mA (pneumatic valve load power supply) |
| Load capacity to FE | 400 nF |
| Max. response time to switch off command | F_WD_TIME + 23 ms |
| Max. power supply per channel | 1.5 A |
| Max. residual current per module | 5 A |
| Nominal operating voltage DC | 24 V |
| Electrical isolation between channel and internal bus | Yes, when using intermediate feed |
| Electrical isolation between channels | no |
| Residual ripple | 2 Vss within voltage range |
| Voltage drop per channel | 0.6 V |
| Permissible voltage fluctuations | -15 % / +20 % |
| Certification | c UL us – Recognized (OL) |
| CE marking (see declaration of conformity) | as per EU machinery directive |
| Certificate issuing authority | German Technical Control Board (TÜV) Rheinland 01/205/5294.01/18 |
| Corrosion resistance class (CRC) | 1 – Low corrosion stress(when installed) |
| Storage temperature | -20 °C … 70 °C |
| Degree of protection | Depends on manifold block |
| Ambient temperature | -5 °C … 50 °C |
| Note on ambient temperature | Observe derating curve for pneumatic interface |
| PFH | 1.0E-9 |
| Product weight | 50 g |
| Max. address capacity outputs | 6 byte |
| Note on outputs | 1 internal channel for switching off pneumatic valve voltage2 external outputs |
| Max. address capacity inputs | 6 byte |
| Max. cable length | 200 m |
| Switching logic at outputs | PM-switching |
| Note on materials | RoHS-compliant |
| Housing material | PA-reinforcedPC |
