| Display range | 0 bar … 10 bar |
| Symbol | 00991463 |
| Pressure gauge nominal size | 15 |
| Structural design | Bourdon tube pressure gauge without measuring mechanism |
| Type of mounting | Line installation |
| Operating medium | Inert gasNeutral liquids |
| Operating pressure | 0 MPa … 1 MPa |
| Operating pressure | 0 bar … 10 bar |
| Operating pressure | 0 psi … 145 psi |
| Intermittent load factor | 0.66 |
| Measurement accuracy class | 5 |
| Degree of protection | IP53 |
| Temperature of medium | -20 °C … 60 °C |
| Ambient temperature | -20 °C … 60 °C |
| Note on materials | RoHS-compliant |
| Connection position | Centered on rear side |
| Pneumatic connection | M5 |
| Material of screwed trunnion | Brass |
| Housing material | Steel |
| Inspection window material | PC |
| Housing colour | Black |
| Product weight | 10 g |
| Information on operating and pilot media | No acetyleneNo oxygen |
