QHA300 – FACTORY HELP

Description

Application

IT hardware for operation of moneo

moneo software preinstalled

ensured secure IT operation of the moneo software

providing memory capacity and processing power

Easy set-up without requiring special IT knowledge

optimised for DataScience applications with moneo

Content description

including appliance management system (AMS) for configuration and maintenance

Compatibility

can be used independent of IT infrastructure

can be integrated in IT network structure at any time

Connectivity

interfaces for sensor and IT network

Maintenance and support

integrated update, back-up and support functions via Appliance Management System

Electrical data

Operating voltage [V]	10…36 DC
Power consumption [W]	21; (maximum: 47)

Outputs

Number of video outputs	2; (DisplayPort)

Software / programming

Included licences	appliance management system (AMS)
Note on licence	hardware bound; licences required for the operation of moneo products have to be ordered separately
Operating system	Debian Linux 11

AMS

Language	German; English; French; Italian; Spanish; Portuguese; Chinese; Japanese; Korean

AMS console

Language	English

System requirements

Web browser	Google Chrome; Mozilla Firefox; (supported versions: see current release notes)

Interfaces

Communication interface	Ethernet; RS232; USB
Number of Ethernet interfaces	3; (GBit)
Number of R232 interfaces	4; (RS232/RS422/RS485)
Number of USB interfaces	4; (3 x USB 3.2 Gen1; 1 x USB 2.0 Type A)

Operating conditions

Ambient temperature [°C]	0…70
Storage temperature [°C]	-20…60
Max. relative air humidity [%]	95; (40 °C non condensing)
Protection	IP 40

Tests / approvals

Shock resistance

IEC60068-2-27

50 g 11 ms

Vibration resistance

IEC 60068-2-64

4 Grms / 5…500 Hz

Mechanical data

Weight [g]	2185.1
Dimensions [mm]	45 x 140 x 200

Hardware

Processor	Intel Core i5-1145G7E quad-core
TPM chip	V 2.0
BIOS	AMI UEFI (256 Mbit)
Working memory	16 GB
Mass storage	1 TB SSD

Remarks

Notes	licences required for the operation of moneo products have to be ordered separately
Pack quantity	1 pcs.
