| Nominal width | 7.2 mm |
| Operating pressure for entire temperature range | -0.95 bar … 12 bar |
| Standard nominal flow rate | 1350 l/min |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] |
| Information on operating and pilot media | Operation with oil lubrication possible |
| Corrosion resistance class (CRC) | 1 – Low corrosion stress |
| Ambient temperature | -10 °C … 60 °C |
| Nominal tightening torque | 21.5 Nm |
| Tolerance for nominal tightening torque | ± 15% |
| Product weight | 82 g |
| Pneumatic connection 1 | Internal thread G3/8 |
| Note on materials | RoHS-compliant |
