$277,00
| Measuring range [l/min] | 2…50 |
|---|---|
| Process connection | threaded connection G 1/2 |
| Media | Liquids; water; glycol solutions; coolants |
|---|---|
| Medium temperature [°C] | -10…100 |
| Pressure rating [bar] | 40 |
| Pressure rating [Mpa] | 4 |
| Operating voltage [V] | 18…32 DC; (to SELV/PELV) |
|---|---|
| Current consumption [mA] | < 35 |
| Protection class | III |
| Reverse polarity protection | yes |
| Output signal | analogue signal |
|---|---|
| Analogue current output [mA] | 4…20 |
| Max. load [Ω] | 500 |
| Short-circuit protection | yes |
| Overload protection | yes |
| Measuring range [l/min] | 2…50 |
|---|
| Repeatability [% of the final value] | 1 |
|---|---|
| Measuring error [% of the final value] | ± 5 |
| Response time [s] | < 0.01 |
|---|
| Ambient temperature [°C] | 0…60 |
|---|---|
| Storage temperature [°C] | -15…80 |
| Protection | IP 65; IP 67 |
| EMC |
|
||||
|---|---|---|---|---|---|
| Shock resistance |
|
||||
| Vibration resistance |
|
||||
| MTTF [years] | 778 |
| Weight [g] | 544 |
|---|---|
| Materials | brass chemically nickel-plated; PP; stainless steel (1.4404 / 316L); aluminium anodised; PA |
| Materials (wetted parts) | stainless steel (316 / 1.4401); brass; brass chemically nickel-plated; PP; PPS; O-ring: FKM |
| Process connection | threaded connection G 1/2 |
| Switching cycles mechanical | 10 million |
| Remarks |
|
||
|---|---|---|---|
| Notes | Please note the changed housing design! | ||
| Pack quantity | 1 pcs. |
| Connection | Connector: 1 x M12; coding: A |
|---|
|
|
|
|---|
