SF2405

SF2405

Reliable monitoring of aggressive liquids in pipes
For connection to an evaluation unit
Ceramic materials for contact with the medium
Robust design for use in harsh industrial environments
Simple process connection via adapter

SKU: SF2405

$244,40

Description

Product characteristics

Probe length L [mm]	12
Process connection	G 1/4 external thread

Application

Media	Liquids; aggressive media
Medium temperature [°C]	5…70
Pressure rating [bar]	30

Liquids

Medium temperature [°C]	5…70

Electrical data

Connection to control monitor	VS3000

Measuring/setting range

Probe length L [mm]	12

Liquids

Setting range [cm/s]	3…60
Greatest sensitivity [cm/s]	3…40

Accuracy / deviations

Temperature gradient [K/min]	7

Response times

Response time [s]	2…20

Liquids

Response time [s]	2…20

Operating conditions

Protection	IP 67

Tests / approvals

Shock resistance

DIN IEC 68-2-27

40 g (11 ms)

Vibration resistance

DIN IEC 68-2-6

10 g (55…2000 Hz)

MTTF [years]

8648

Mechanical data

Weight [g]	41.5
Housing	threaded type
Materials	ceramics (99.7 % Al2O3)
Materials (wetted parts)	ceramics (99.7 % Al2O3)
Process connection	G 1/4 external thread
Installation length EL [mm]	27

Accessories

Items supplied

sealings: 1, PTFE

Remarks

Remarks

For sealing use the supplied PTFE packing washer.

Pack quantity

1 pcs.

Electrical connection

Connection	Connector: 1 x M12; coding: A; Maximum cable length: 100 m
