| Nominal width | 3 mm |
| Suction cup diameter | 30 mm |
| Effective suction cup diameter | 25 mm |
| Connection position | Top |
| Symbol | 00991485 |
| Suction cup shape | Round bellows, 1.5 convolutions |
| Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] |
| Ambient temperature | -20 °C … 80 °C |
| Breakaway force at 70% vacuum | 34 N |
| Holding force at nominal operating pressure | 34 N |
| Mounting thread | G1/8 |
| Suction cup mounting | G 1/8 |
| Vacuum connection | G1/8 |
| Color | Black |
| Shore hardness | 60 +/- 5 |
| Material of screwed trunnion | Brass |
| Note on materials | RoHS-compliant |
| Suction cup material | NBR |
