$392,10
| Frequency range [Hz] | 2…10000 |
|---|---|
| Measuring principle | capacitive |
| Measuring range of vibration [mm/s] | 0…45 |
|---|
| Measuring range of vibration |
|
|---|
| Application | industrial machines |
|---|
| Operating voltage [V] | 18…30 DC |
|---|---|
| Current consumption [mA] | < 50 |
| Min. insulation resistance [MΩ] | 100; (500 V DC) |
| Protection class | III |
| Reverse polarity protection | yes |
| Sensor type | microelectromechanical system (MEMS) |
| Number of inputs and outputs | Number of digital outputs: 2 |
|---|
| Output signal | switching signal; IO-Link |
|---|---|
| Electrical design | PNP/NPN; (configurable) |
| Number of digital outputs | 2 |
| Output function | normally open / normally closed |
| Max. voltage drop switching output DC [V] | 2 |
| Max. current load per output [mA] | 100 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
| Note on setpoint SP |
|
|
|---|---|---|
| Frequency range [Hz] | 2…10000 | |
| Measuring principle | capacitive | |
| Number of measurement axes | 1 |
| Measuring range of vibration [mm/s] | 0…45 |
|---|---|
| Set point SP [mm/s] | 0.2…45 |
| Reset point rP [mm/s] | 0…44.8 |
| In steps of [mm/s] | 0.2 |
| Measuring range of vibration |
|
||
|---|---|---|---|
| Set point SP |
|
||
| Reset point rP |
|
||
| In steps of |
|
| Measuring range of vibration | 1…50 |
|---|---|
| Set point SP | 2…50 |
| Reset point rP | 1…49 |
| In steps of | 1 |
| Measuring range [°C] | -30…80 |
|---|---|
| Resolution [°C] | 0.1 |
| Set point SP [°C] | -28…80 |
| Reset point rP [°C] | -30…78 |
| In steps of [°C] | 2 |
| Accuracy | ≤ 4 kHz +/-10 %;≥ 4…10 kHz: < 3 dB |
|---|---|
| Accuracy [K] | ± 2,5 K + (0,2 x (Umgebungstemperatur – Oberflächentemperatur)) |
| Linearity deviation | 2 % |
| Parameter setting options | Software |
|---|---|
| Diagnostic functions | self-test |
| Communication interface | IO-Link | ||||||
|---|---|---|---|---|---|---|---|
| Transmission type | COM2 (38,4 kBaud); COM3 (230,4 kBaud) | ||||||
| IO-Link revision | 1.1 | ||||||
| SDCI standard | IEC 61131-9: 2013-07 | ||||||
| Profiles | Blob (0x0030); Measuring sensor (0x800A); Common Profile (0x4000) | ||||||
| SIO mode | yes | ||||||
| Required master port type | A | ||||||
| Process data analogue | 10 | ||||||
| Process data binary | 2 | ||||||
| Min. process cycle time [ms] | 3.6 | ||||||
| IO-Link functions (acyclical) | filter for v-RMS, a-RMS, a-Peak; Hysteresis; window; switch points; switching logic | ||||||
| Supported DeviceIDs |
|
||||||
| Note |
|
| Ambient temperature [°C] | -30…80 |
|---|---|
| Storage temperature [°C] | -30…80 |
| Protection | IP 67; IP 68; IP 69K |
| EMC |
|
||||||
|---|---|---|---|---|---|---|---|
| Shock resistance |
|
||||||
| Vibration resistance |
|
||||||
| MTTF [years] | 299 | ||||||
| UL approval |
|
| Weight [g] | 116 |
|---|---|
| Type of mounting | set screw |
| Materials | housing: stainless steel (1.4404 / 316L) |
| Tightening torque [Nm] | 8 |
| Items supplied |
|
|---|
| Pack quantity | 1 pcs. |
|---|
| Connector: 1 x M12; coding: A; Maximum cable length: 20 m |
